High-Nickel Alloy Welded Bellows



This product is a standard welded bellows made of a material equivalent to Hastelloy® C-22.*

Process gas exhaust systems for semiconductor manufacturing, chemical processing equipment, flue gas desulfurization (FGD) systems, hazardous and waste incineration plants, and radioactive waste treatment facilities.

  • A W(tungsten)-added Ni-Cr-Mo alloy offering outstanding corrosion resistance in both reducing and oxidizing environments.
  • It demonstrates superior durability against a wide range of corrosive conditions.
  • The bellows are fabricated by welding ultra-thin metal sheets of only 0.08 mm thickness into a flexible corrugated structure.
  • Compared to our conventional models, the new design achieves a 20% (approx.) reduction in size and weight, contributing to more compact system integration.



※Please contact us for product details and quotations.

Inquiry　

 Download Documentation 　　




　Welded Bellows Study Specs　



　Welded Bellows Standard dimensions　







* Hastelloy® C-22 is a registered trademark of Haynes international. Inc.

Typical Specifications


We have a lineup of single bellows.
It can be used under the following pressure, temperature, and specified life conditions.
Pressure Condition (Internal) Vacuum／(External) Atmospheric pressure
Temperature Conditions Normal temperature (max 250℃ during baking)
Operating Conditions Axial displacement only
Amount Of Leak 1×10-9 Pa・m3/s or less
Material (Bellows) equivalent to Hastelloy ® C-22* (Bellows single item only)
Specified Life (Single bellows) 10,000, 100,000, 1,000,000 times

* Hastelloy® C-22 is a registered trademark of Haynes international. Inc.

Available in custom sizes　*Outer diameters：18～270mm


1 million repetition life series / Unit mm

Typical size examples
 Model Inner diameter Outer diameter
NH10018-1 8 18
NH10022-1 8 22
NH10030-1 17 30
NH10036-1 22 36
NH10038-1 26 38
NH10051-1 36 51
NH10070-1 50 70
NH10090-1 60 90
NH100150-1 120 150
NH100270-1 206 270


Individually Designed Product

If standard models do not meet your requirements, we offer customized solutions.

  • Compact designs available
  • Multi-directional displacement options
  • Suitable for reverse pressure applications, including external vacuum conditions
